ANSI Polypropylene Backing Flange BFPA032

ansi_pp_backing_flange1
ansi_pp_backing_flange1ansi_pp_backing_flange2ansi_pp_backing_flange3
All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement.

Size

Pipe OD
(mm)		 Galvanised Code Flange Size OD
(mm)		 ID
(mm)		 PCD
(mm)		 T
(mm)		 Bolt Holes
NO. x DIA		 Bolt Weight
(kg)
32 BFGDIN16032 1" 115 44 85 12 4 x 14 M16 0.78
40 BFGDIN16040 1 1/4" 140 52 100 14 4 x 18 M16 1.35
50 BFGDIN16050 1 1/2" 150 62 110 14 4 x 18 M16 1.5
63 BFGDIN16063 2" 165 78 125 16 4 x 18 M16 1.96
75 BFGDIN16075 2 1/2" 185 92 145 16 8 x 18 M16 2.29
90 BFGDIN16090 3" 200 108 160 18 8 x 18 M16 2.86
110 BFGDIN16110 4" 220 128 180 18 8 x 18 M16 3.27
125 BFGDIN16125 5" 250 140 210 25 8 x 18 M16 6.23
125 BFGDIN161254 4" 220 140 180 18 8 x 18 M16 2.92
140 BFGDIN16140 5" 250 158 210 18 8 x 18 M16 3.89
160 BFGDIN16160 6" 285 178 240 20 8 x 22 M20 5.64
180 BFGDIN16180 6" 285 195 240 20 8 x 22 M20 4.86
200 BFGDIN16200 8" 340 235 295 24 12 x 22 M20 8.09
225 BFGDIN16225 8" 340 240 295 24 12 x 22 M20 7.74
250 BFGDIN16250 10" 405 290 355 30 12 x 26 M24 13.31
280 BFGDIN16280 10" 405 300 355 30 12 x 26 M24 12.22
315 BFGDIN16315 12" 460 345 410 34 12 x 26 M24 17.75
